PTFE O-Ring

Kaxite Sealing's PTFE O-Ring offers unparalleled performance for high-temperature and corrosive applications. Its durable PTFE material ensures long-lasting sealing, ideal for industrial and automotive uses. Experience reliability and peace of mind with our distinct design, solving common leakage issues and enhancing efficiency. Choose Kaxite Sealing for superior quality that stands out from the rest.

Send Inquiry

Product Description

[ Main properties ]

We can produce other no-nominal compound o-ring.

Property		Unit
Property		Unit	A	B	C
Normal Ckonditions	Hardness	JIS Hs	70-90	70-90	60-75
	Elongation,min	%	60	60	80
	Tensile Strength,min	MPa	16	16	16
	Compressibility	%	50-60	50-60	60-75
	Recovery	%	>85	>85	>70
	Permanentset	%	<10	<10	<20
230X24h hot air ageing	Change of hardness,max.	JIS Hs	-5-+5	-5-+5	-5-+5
	Change of tensile strength,max.	%	-15	-15	-15
	Change of elongation,max.	%	-20	-20	-20
Compression permanentset	175X70h	%	20	20	30
Colour			blown	black	red
Applications	Temperature Limits		-20-250	-20-200	-50-200
	Pressure Limits	MPa	0-35
	Strong caustics,moderate acids,chlorine,gases,wter,steam,hydrocarbons,hydrogen and aluminum fluoride except element fluorine and fusion sodium.

[ Specifications ]

Setion Diameter	Nominal Inside Diameter	Setion Diameter	Nominal Inside Diameter
1.800.10	200.10-3001.60	6.000.13	800.80-4002.00
2.600.10	200.15-3001.60	6.300.14	800.80-4002.00
3.550.10	250.15-3001.60	7.000.14	1000.65-10004.00
4.000.10	400.20-3001.60	8.000.16	1101.00-20004.00
4.600.10	400.20-3001.60	10.000.18	2001.50-20006.00
5.000.10	400.25-4001.80	12.000.18	4001.50-6.00
5.300.13	600.30-4001.80	14.000.18	4001.50-6.00
5.500.13	600.30-4001.80	16.000.18	4001.50-6.00
5.700.13	600.30-4002.00
